U-PVC solvent socket with female reinforced thread

SKU: AFX102
Auswahl Steuerzone / Lieferland
from
0,77 €
incl. 19% VAT , plus shipping costs
  • Available immediately
View item details in PDF The images are provided for illustrative purposes only, they do not constitute a contractual element and refer to a single variant/size. Images, technical data, dimensions and drawings are not binding. We reserve the right to make changes at any time without notice. The dimensions are defined and shown more clearly in the item description. Other dimensions only serve as support and better clarification."
How to measure a threaded fitting
  • Available immediately
   Variants

Item no.
Variation
D
G
L
L1
L2
S
Price
Quantity
AFX102.016.016
16mm x 3/8"
16
3/8" (16,66mm)
35
16
16
32
1,49 €*
pc.:
AFX102.020.020
20mm x 1/2"
20
1/2" (20,96mm)
35
16
16
29
0,77 €*
pc.:
AFX102.025.025
25mm x 3/4"
25
3/4" (26,44mm)
41
19
19
35
0,86 €*
pc.:
AFX102.032.032
32mm x 1"
32
1" (33,25mm)
47
22
22
43
1,13 €*
pc.:
AFX102.040.040
40mm x 1 1/4"
40
1 1/4" (41,91mm)
55
27
23
49
1,37 €*
pc.:
AFX102.050.050
50mm x 1 1/2"
50
1 1/2" (47,80mm)
69
31
32
65
2,13 €*
pc.:
AFX102.063.063
63mm x 2"
63
2" (59,61mm)
76
39
33
73,5
2,67 €*
pc.:
AFX102.075.075
75mm x 2 1/2"
75
2 1/2" (75,18mm)
80,5
31
45
15,30 €*
pc.:
AFX102.090.090
90mm x 3"
90
3" (87,88mm)
91,5
35
51,5
109
19,88 €*
pc.:

incl. 19% VAT , plus shipping costs

All dimensions are shown in millimeters, all weights are shown in grams.
The images are provided for illustrative purposes only, they do not constitute a contractual element and refer to a single variant/size. Images, technical data, dimensions and drawings are not binding. We reserve the right to make changes at any time without notice. The dimensions are defined and shown more clearly in the item description. Other dimensions only serve as support and better clarification.

   Description

U-PVC solvent socket with female reinforced thread



 Anschluss:        solvent socket x female thread reinforced
 Gewinde:  BSP pipe thread G, none self-sealing, sealing with Teflonband or similar
 Temperatur:  up to 45°C constant, short term 60°C
 Arbeitsdruck (PN):  max. 16 bar till 20°C
 Drucktest:  pressure test after ISO 9393-2:2005(E) test pressure 1,5 x PN 16
 Material:  PVC-U
 Farbe:  Grey
 Einsatzbereich:
Gewindemuffe

Adaptor Socket, solvent socket x female thread reinforced

Der Edelstahlring kompensiert den auf das Gewinde einwirkenden Druck und verhindert eine Beschädigung oder Aufplatzen der Gewindemuffe. Die mit Edelstahlring verstärkte Gewindemuffe kann für höhere Druckstufen bis max. 16 bar eingesetzt werden.


DOWNLOAD PVC-U technische Charakteristik

DOWNLOAD Kleben von PVC-U Rohren und -Fittings

DOWNLOAD die Gewindekennung - oder warum 1" eben keine 25,4mm sind

DOWNLOAD abdichten und verbinden von Kunststoffgewinden

DOWNLOAD chemische Beständigkeit von Kunststoffen

DOWNLOAD äußere Merkmale von Spritzgussfittings

DOWNLOAD RoSH Bestätigung - Coraplax CH PVC-U Fittings und Armaturen

DOWNLOAD Unbedenklichkeit Kontakt mit Trinkwasser und Nahrung - Coraplax PVC-U Fittings
