U-PVC elbow 45° with hose tail

SKU: AF0415
Auswahl Steuerzone / Lieferland
from
3,45 €
incl. 19% VAT , plus shipping costs
  • Available immediately
View item details in PDF The images are provided for illustrative purposes only, they do not constitute a contractual element and refer to a single variant/size. Images, technical data, dimensions and drawings are not binding. We reserve the right to make changes at any time without notice. The dimensions are defined and shown more clearly in the item description. Other dimensions only serve as support and better clarification."
How to measure a threaded fitting

wichtiger Hinweis

der Artikel wird speziell für Ihren Auftrag angefertigt - keine Rückgabe, kein Widerruf

  • Available immediately
   Variants

Product picture
Item no.
Variation
D
D1
DN
L
L1
Hose ø inside
Price
Quantity
U-PVC elbow 45° with hose tail
AF0415.020.008
8 x 8mm
8
8
5
69
69
8
3,45 €*
pc.:
U-PVC elbow 45° with hose tail
AF0415.020.010
10 x 10mm
10
10
6
69
69
10
3,45 €*
pc.:
U-PVC elbow 45° with hose tail
AF0415.020.012
12 x 12mm
12
12
8
72
72
12
3,45 €*
U-PVC elbow 45° with hose tail 2fach 16mm
AF0415.020.016
16 x 16mm
16
16
11,5
73
73
16
3,45 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 20mm
AF0415.020.020
20 x 20mm
20
20
13
90
90
20
3,45 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 25mm
AF0415.025.025
25 x 25mm
25
25
18
103
103
25
4,18 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 32mm
AF0415.032.032
32 x 32mm
32
32
24
103
103
32
5,84 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 38mm
AF0415.038.038
38 x 38mm
38
38
25
148
148
38
6,59 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 40mm
AF0415.040.040
40 x 40mm
40
40
27
138
138
40
6,18 €*
pc.:
U-PVC elbow 45° with hose tail 50 x 38mm
AF0415.050.038
50 x 38mm
38
50
25
147
160
50 x 38
7,18 €*
pc.:
U-PVC elbow 45° with hose tail 2fach 50mm
AF0415.050.050
50 x 50mm
50
50
36
160
160
50
7,91 €*
pc.:

incl. 19% VAT , plus shipping costs

All dimensions are shown in millimeters, all weights are shown in grams.
The images are provided for illustrative purposes only, they do not constitute a contractual element and refer to a single variant/size. Images, technical data, dimensions and drawings are not binding. We reserve the right to make changes at any time without notice. The dimensions are defined and shown more clearly in the item description. Other dimensions only serve as support and better clarification.

   Description

PVC-U Winkel 90° mit 2fach Schlauchtülle

Anschluss:
2fach Schlauchtülle
Temperatur:
bis 45°C konstant, kurzzeitig 60°C
Arbeitsdruck (PN):
max. 10 bar bei 20°C Medium Wasser
Material:
PVC-U
Farbe:
Grau
DOWNLOADRoHS Bestätigung HTC
DOWNLOAD chemische Beständigkeit von Kunststoffen
